BASS CHORUS BCH100
Thank you for showing your confidence in us by purchasing the BEHRINGER BASS
CHORUS BCH100. This ultimate effects pedal is specifically designed to match the range
and applications of bass guitars. Thanks to its high-performance features you get super
thick chorus with unbelievable stereo effect.
The chorus effect slightly detunes the original signal. A very pleasant detune effect is
created relative to the pitch variation. The chorus effect is often used for dispersing signals.
1. CONTROLS
Top view
The LEVEL control adjusts the output level.
The SHAPE control lowers the amount of ultra-low frequencies in the effect signal
to achieve more defined tone and avoid muddiness of sound.
The RATE control determines the chorus effect speed.
Turn up the DEPTH control to achieve a more full and deeper effect sound.
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The two 1/4" TS connectors OUT A and OUT B send the signal to your amp. Use
both connectors if you want to achieve full stereo chorus effect. For mono use just
plug in OUT A.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery, press the hinges with a ballpen and remove the pedal cover. Be
careful not to scratch the unit.
