BASS LIMITER ENHANCER BLE400
Ultimate Dynamics Eects Pedal
Thank you for showing your condence in us by purchasing the BEHRINGER BASS LIMITER ENHANCER
BLE400. This ultimate eects pedal is specically designed to smoothen harsh volume peaks when using
dynamic slaps or other playing styles. Thanks to its high-performance features you get full dynamics and
tone control for absolute exibility and limitless creative options.
A limiter reduces the dynamic range of a signal. This means that signal peaks will be attenuated and the
level dierences between loudest and softest playing are reduced. This results in a more powerful and
pressure-rich tone. The loss of high frequencies due to compression can be compensated by using an
enhancer that adds high-frequency harmonics to the sound.
1. Controls
(1) The LEVEL control adjusts the output level.
(2) Turn up the ENHANCE control to achieve more presence and bass clarity.
(3) The RATIO control determines the amount of compression when the chosen threshold (see below)
value is exceeded.
(4) Use the THRESH(old) control to dene a level threshold. When this value is exceeded by the input
signal, the BLE400 starts limiting with the chosen amount of ratio.
(5) The ON/BATT LED illuminates when the eect is activated. It also serves as a battery level indicator.
(6) Use the footswitch to activate/deactivate the eect.
(7) Use this ¼" TS IN connector to plug in the instrument cable.
(8) The ¼" TS OUT connector sends the signal to your amp.
Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery,
press the hinges with a ballpen and remove the pedal cover. Be careful not to scratch the unit.
(5)
(1)
(8)
(7)
(4)
(6)
(3)(2)
