9 V-TONE GM108 User Manual
R
L
R
L
ring
tip
sleeve
tip
tip
sleeve
sleeve
Fig. 5.3: Stereo adapter cable
sleevesleeve
tiptip
Fig. 5.4: Mono adapter cable
6. Specications
Audio Inputs
Guitar input connector ¼" TS mono connector
CD input connector ¼" TRS stereo connector
Audio Outputs
Headphone output connector ¼" TRS stereo connector
System Specications
Power amp output 15 Watts RMS into 4 Ohms
Loudspeaker
Type 8" vintage design guitar speaker
Impedance 4 Ohms
Power handling 20 Watts
Power Supply
Mains Voltage
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Dimensions/Weight
Dimmensions (H x W x D) approx. 12 ⁄ x 14 ⁄ x 6 ⁄"
approx. 322 x 357 x 162 mm
Weight approx. 11.3 lbs / 5.15 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or shown.
