BEHRINGER MicroAMP HA400
WELCOME TO BEHRINGER
Thank you for showing your confidence in us by purchasing the
BEHRINGER MicroAMP HA400.
This 4-channel stereo headphone amplifier is designed for use with all
types of headphones and therefore provides maximum flexibility. Its
high-power stereo amplifiers guarantee the highest sonic quality even
at maximum volume. The ultra low-noise 4580 operational amplifiers
ensure outstanding audio performance.
CONNECTORS AND CONTROL ELEMENTS
HA400 connectors and control elements
Connect the power supply unit to your HA400 using the
12 V connector. Connecting the power supply unit to the mains
automatically switches the HA400 on. To disconnect the unit
from the mains, pull out the main cord plug.
+ When installing the product, ensure that the plug is easily
accessible. If mounting in a rack, ensure that the mains can
be easily disconnected by a plug or by an all-pole disconnect
switch on or near the rack.
Connect up to 4 headphones to these 1/4" TRS connectors.
The signal source has to be connected to this 1/4" TRS connector
(INPUT).
+ In case the volume level of the signal source is set too high, the
HA400 may produce distortion!
This ON LED is illuminated as soon as the unit is connected to
the power.
Using the LEVEL controls you can set the volume level of each
headphone output.
+ High volume levels can damage your hearing or your
headphones. Please turn down all volume controls to zero
(all the way to the left) before you power up the amp. Always
make sure you use appropriate volume levels.
SERIAL NUMBER. The serial number of the HA400 is located at the
bottom.
APPLICATIONS
The following figure shows an example of how to use the MicroAMP
HA400.
Example: HA400 wiring
WARRANTY
For our current warranty terms, please refer to our website at
http://www.behringer.com.
