HI BAND FLANGER HF300
Thank you for showing your confidence in us by purchasing the BEHRINGER HI BAND
FLANGER HF300. This high-quality effects pedal delivers incredible flanging effects one
octave higher than usual to take your guitar or keyboard to a new level.
Originally, the flanger effect was generated with two tape recorders running
synchronously. The same audio signal was recorded on both machines. If you put a
finger on the left spool of one of the machines, the spool and the playback speed are
slowed down. The generated delay results in phase shifting of the signals.
1. CONTROLS
Top view
The MANUAL control adjusts the delay length and determines the starting point for
the modulation range. If DEPTH is set to minimum, it controls a static comb filter effect
between dry and delayed signal, which can be used to create resonator-like sounds.
The DEPTH control adjusts the flanger sweep range according to the delay time.
The RATE control adjusts the speed of the flanger’s low frequency oscillator.
The RES(onance) control determines the amount of output signal fed back to the
flanger input to increase the resonance effect. This adds a jet stream like sound to
the flanger effect
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The 1/4" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove
the pedal cover. Be careful not to scratch the unit.
The HF300 has no on/off switch. As soon as you insert the plug into the IN
connector, the HF300 is on. When not in use, remove the plug from the IN
connector. This extends the life of the battery.
