VINTAGE DISTORTION VD1
Authentic Vintage-Style Distortion/Sustainer
Thank you for showing your condence in us by purchasing the BEHRINGER VINTAGE DISTORTION VD1.
This high-quality eects pedal delivers authentic and classic distortion eect—the warm and emotive
tone that has ruled rock for the last 30 years. Thanks to its high-performance features, the VD1
reproduces the natural dynamics of your playing and lets your guitar scream.
1. Controls
(1) The VOLUME control adjusts the output level.
(2) The TONE control lets you raise the high frequencies, resulting in more powerful distortion.
(3) The SUSTAIN control determines the amount of sustain eect.
(4) This LED illuminates when the eect is activated.
(5) Use the footswitch to activate/deactivate the eect.
(6) Use this ¼" TS INPUT connector to plug in the instrument cable.
(7) The ¼" TS OUTPUT connector sends the signal to your amp.
Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located on the bottom. Open the lid to install or replace the 9 V battery.
◊ The VD1 has no on/o switch. As soon as you insert the jack into the in connector,
the VD1 begins running. When not using the VD1, remove the jack from the in connector.
This extends the life of the battery.
The SERIAL NUMBER is located on the bottom.
(1)
(7) (6)
(3)
(5)
(4) (2)
