Chauvet Ch-310 Musical Instrument User Manual



Caution
Do not obstruct the air vents or the fan.
Do not touch unit or lamps while hot.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power 120V~60Hz AC 230V~50Hz AC
Fuse 20mm Glass 7A Fast Blow 20mm Glass 3.15A Fast Blow
Lamps
2 x 120V 300W
Part No 64514
2 x 120V 300W (wired in series)
Part No 64514
Dimensions 380 x 368 x 280mm / 15in x 14.5in x 11in
Weight 11.5kg / 25lbs
User Information (Please complete for your records)
Date Purchased: // Serial No:
Dealer Stamp: Model: CH-310 DOUBLE
DERBY
DD
DD
oo
oo
uu
uu
bb
bb
ll
ll
ee
ee
DD
DD
ee
ee
rr
rr
bb
bb
yy
yy
CH-310
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29
th
Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
European Office:
Unit 18, Hunslet Trading Estate, Leeds, UK
LS10 1BL
Tel: (0113) 276-0755 Fax: (0113) 277-6675
www.ChauvetLighting.com
