ULTRABASS BX300
5. SPECIFICATIONS
AUDIO INPUTS
Passive E-Bass input 1/4" mono jack, unbalanced
Input impedance approx. 1 MW
Active E-bass input 1/4" mono jack, unbalanced
Input impedance approx. 130 kW
Power Amp input 1/4" mono jack, unbalanced
Input impedance approx. 25 kW
Tape input RCA connector, unbalanced
Input impedance approx. 68 kW
AUDIO OUTPUTS
Headphones connector 1/4" stereo jack
Preamp output 1/4" mono jack, unbalanced
Output impedance approx. 1 kW
SYSTEM SPECIFICATIONS
Power amp output 30 Watts into 8 W
LOUDSPEAKER
Type 10B35A8
Impedance 8 W
Power rating 35 Watts RMS
POWER SUPPLY
Mains voltages U.S./Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Power consumption 73 W
Fuse 100 - 120 V ~: T 2 A H
200 - 240 V ~: T 1 A H
Mains connection Standard IEC receptacle
PHYSICAL/WEIGHT
Dimensions (H * W * D) approx. 17 1/4" (440 mm) * 15 3/4" (398 mm) * 10 1/8" (256 mm)
Weight approx. 13.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or
illustrated.
