2 MIDI FOOT CONTROLLER FCB1010 Technical Specifications
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those
listed or illustrated.
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR
RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN. COLORS AND
SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND RESELLERS ARE NOT AGENTS OF MUSIC GROUP AND HAVE ABSOLUTELY NO
AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR
MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL RIGHTS RESERVED. © 2012 MUSIC GROUP IP LTD. TRIDENT CHAMBERS,
WICKHAMS CAY, P.O. BOX 146, ROAD TOWN, TORTOLA, BRITISH VIRGIN ISLANDS
MIDI FOOT CONTROLLER FCB1010
Ultra-Flexible MIDI Foot Controller with 2 Expression Pedals
and MIDI Merge Function
Professional and ultra-exible MIDI foot controller
10 banks of presets, each with 10 fully user-editable presets
2 expression pedals with freely assignable MIDI channel, controller number and range
Simultaneous transmission of 5 MIDI program change commands and 2 MIDI controllers per preset
MIDI note commands for trigger and tap-tempo applications
2 programmable and relay-controlled switch jacks, e.g. to select channels on any guitar amp
No need to take a seat-everything can be easily programmed while standing
Global setup allows for individual customization
Backup function via MIDI SysEx
MIDI merge function allows for soft through and merging of controller and input data
Built-in power supply ensures trouble-free operation
High quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
MIDI Interface
Type 5-pin DIN jacks IN and OUT / THRU
Display
Type 3-digit LED
Switching Output
Type ¼" jack (open)
Power Supply
Voltage
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption 10 W
Fuse 100 - 120 V~: T 100 mA L 250 V
200 - 240 V~: T 50 mA L 250 V
Mains connection Standard IEC connector
Dimensions/Weight
Dimensions (H x W x D) approx. 2 ⁄ x 8 ¾ x 27"
approx. 60 x 221 x 687 mm
Weight approx. 9.55 lbs / 4.34 kg
