HELLBABE HB01
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS
PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO
LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH
OR STATEMENT CONTAINED HEREIN. COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH
AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND RESELLERS ARE NOT AGENTS OF MUSIC GROUP AND HAVE ABSOLUTELY NO
AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS
MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND
RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL RIGHTS RESERVED.
© 2012 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands
The BATTERY COMPARTMENT is located at the bottom of the unit. Open the lid to install or replace the 9 V battery.
◊ The HB01 has no on/o switch. As soon as you insert the jack into the IN connector, the HB01 begins running.
When not using the HB01, remove the jack from the IN connector. This extends the life of the battery.
The SERIAL NUMBER is located at the bottom of the unit.
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself.
Contact our qualied servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.
3. Warranty
Please register your new BEHRINGER equipment right after your purchase by visiting http://behringer.com and read the terms and
conditions of our warranty carefully.
4. Specications
Input
Connector ¼" TS
Impedance 1 MΩ
Output
Connector ¼" TS
Impedance 1 kΩ
Output/Bypass
Connector ¼" TS
Impedance 1 kΩ
Power Supply
9 V, 100 mA DC regulated
PSU-SB-CN BEHRINGER 220 VAC adaptor China
PSU-SB-EU BEHRINGER 230 VAC adaptor Europe
PSU-SB-JP BEHRINGER 100 VAC adaptor Japan
PSU-SB-SAA BEHRINGER 240 VAC adaptor Australia
PSU-SB-UK BEHRINGER 240 VAC adaptor UK
PSU-SB-UL BEHRINGER 120 VAC adaptor USA
Power connector 2 mm DC jack, negative center
Battery 9 V type 6LR61
Power consumption 30 mA
Dimensions/Weight
Dimensions (H x W x D) 3.8 x 4.7 x 10" / 99 x 120 x 254 mm
Weight 2.6 lbs / 1.2 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may
be made from time to time to existing products without prior notice. Specifications and appearance may therefore differ from
those listed or shown.
