POWERPLAY PRO HA4600
5. SPECIFICATIONS
5. SPECIFICATIONS
AUDIO INPUTS
MAIN-Input
Connectors XLR- and 1/4" TRS
Type HF-filtered, servo-balanced input
Impedance 40 kOhm balanced, 20 kOhm unbalanced
Max. input level +21 dBu balanced and unbalanced
CMRR typically 40 dB, >55 dB @ 1 kHz
AUX IN- and DIRECT IN-Input
Connectors 1/4" TRS (tip = left, ring = right, sleeve = ground)
Type unbalanced
Impedance >15 kOhm unbalanced
Max. input level +21 dBu unbalanced
CMRR typically 40 dB, >50 dB @ 1 kHz
AUDIO OUTPUTS
Connectors XLR- and 1/4" TRS
Type balanced / unbalanced
Impedance depends on the input impedance
Max. output level +21 dBu balanced and unbalanced
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 100 kHz, +/-3 dB
Noise >99 dBu, unweighted, 22 Hz to 22 kHz (>95 dB @ +4dBu)
Distortion (THD) 0.005 % typ. @ +4 dBu, 1 kHz, Gain 1
POWER AMPLIFIER
Max. output power +26 dBm
Min. output impedance 100 Ohm
FUNCTION CONTROLS
Input level variable
Balance per channel Mix between Aux and Main signals
Output level per channel variable
FUNCTION SWITCHES
Left mute mutes the left signal of the respective channel
Right mute mutes the right signal of the respective channel
Mono switches this channel to mono
DISPLAYS
Input level 4-digit LED-display: -24/-12/0/+12 dBu
Output level 8-digit LED-display: -24/-18/-12/-6/0/+6/+12 dBu/CLIP
POWER SUPPLY
Mains voltage USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
general export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Power consumption 40 W
Fuses 100 - 120 V ~: T 630 mA H
200 - 240 V ~: T 315 mA H
Mains connection standard IEC receptacle
DIMENSIONS AND WEIGHT
Dimensions approx. 1 ¾" (44.5 mm) * 19" (482.6 mm) * 8 ½" (217 mm)
