Behringer TP300 Music Pedal User Manual



ULTRA TREMOLO/PAN TP300
Classic Stereo Tremolo/Panner Eects Pedal
Thank you for showing your condence in us by purchasing the BEHRINGER ULTRA TREMOLO/PAN TP300.
This high-quality eects pedal is designed to provide guitarists easy-to-use tremolo and panning
eect styles. Thanks to its high-performance features you get the classic, warm and mind-bending
tremolo/panning eects of vintage ‘60s amps.
The tremolo eect is achieved by periodic modulation of the input signal level. This results in a
continuous change from low to high level that has a quivering, tremulous sound character. In panning
mode the signal is periodically moved from one side of stereo image to the other.
1. Controls
(1) The MODE switch selects between 2 tremolo modes and 2 panning modes.
PAN: Signal uctuates between the left and right side of the stereo image. For this eect both
outputs (stereo) have to be used. In Triangle Wave mode the signal uctuates smoothly while in
Square mode it changes sharply.
TREMOLO: Periodic changes of the signal level. In Triangle Wave mode the signal level uctuates
smoothly while in Square mode it changes sharply.
(2) The DEPTH control adjusts the amount of uctuation concerning the signal level (TREMOLO)
and signal position (PAN).
(3) The RATE control adjusts the speed of the uctuation concerning the signal level (TREMOLO)
and signal position (PAN).
(4) The RATE LED displays the speed of the eect determined with the RATE control (ashes).
(5) The ON/BATT LED illuminates when the eect is activated. It also serves as a battery level indicator.
(6) Use the footswitch to activate/deactivate the eect.
(5)
(1)
(4)
(6)
(2)
(3)
(8) (7)
