ULTRA TREMOLO/PAN TP300
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE
MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS
WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.
COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS
ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR
IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM
OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS
WRITTEN PERMISSION OF MUSICGROUPIPLTD. ALL RIGHTS RESERVED. © 2012 MUSICGroupIPLtd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town,
Tortola, British Virgin Islands
(7) Use the ¼" TS IN A and IN B connectors to plug in the instrument cables. For mono use plug in IN A only.
(8) The two ¼" TS OUT A and OUT B connectors send the signal to your amp. Use both connectors if
you want to achieve full stereo eect. For mono use plug in OUT A only.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery
(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to
scratch the unit.
◊ The TP300 has no on/o switch. As soon as you insert the plug into the in connector,
the TP300 is on. When not in use, remove the plug from the in connector. This extends
the life of the battery.
The SERIAL NUMBER is located at the underside.
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories.
Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,
especially when power supply cord or plug is damaged.
3. Warranty
Please register your new BEHRINGER equipment right after your purchase by visiting
http://behringer.com and read the terms and conditions of our warranty carefully.
4. Specications
In A
Connector ¼" TS
Impedance 500 k
Impedance mono 250 k
In B
Connector ¼" TS
Impedance 500 k
Out A / Out B
Connector ¼" TS
Impedance 1 k
Power Supply
Power consumption 30 mA
BEHRINGER PSU-SB
Mains Connection
Connector mains plug
Voltage 100 V - 230 V, 50/60 Hz
Device Connection
Connector 2 mm DC jack,
negative center
Voltage 9 V𝌂
Current 100 mA regulated
Battery Power Supply
Battery 9 V type 6LR61
Power consumption 30 mA
Physical/Weight
Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"
(H x W x D) approx. 54 x 70 x 123 mm
Weight approx. 0.73 lbs / 0.33 kg
BEHRINGER is constantly striving to maintain the
highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing
products without prior notice. Specifications and appearance
may therefore differ from those listed or shown.
