EURORACK
UB1002FX/UB1202FX
Headphones output
Type 1/4" TRS connector, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
Main mix system data
2
Noise
Main mix @ -oo,
Channel fader -oo -105 dB / -108 dB A-weighted
Main mix @ 0 dB,
Channel fader -oo -94 dB / -97 dB A-weighted
Main Mix @ 0 dB,
Channel fader @ 0 dB -83 dB / -85 dB A-weighted
FX section
Converter 24-Bit Sigma-Delta
Sampling rate 40 kHz
Power supply
Power consumption UB1002FX: 16 W
UB1202FX: 17 W
Mains voltage
USA/Canada 120 V~, 60 Hz, MXUL6 adapter
U.K./Australia 240 V~, 50 Hz, MXUK6 adapter
Europe 230 V~, 50 Hz, MXEU6 adapter
China 220 V~, 50 Hz, MXCN6 adapter
Japan 100 V~, 60 Hz, MXJP6 adapter
Dimensions
UB1002FX
Dimensions (H x W x D) 1 5/6" / 1 1/2" x 7 2/5" x 8 2/3"
(47 mm / 37 mm x 189 mm x
220 mm)
Weight (net) approx. 2.31 lbs (1.05 kg)
UB1202FX
Dimensions (H x W x D) 1 5/6" / 1 1/2" x 9 1/2" x 8 2/3"
(47 mm / 37 mm x 242 mm x
220 mm)
Weight (net) approx. 2.97 lbs (1.35 kg)
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all
channels on main mix; channels 1/3 as far left as possible, channels 2/4 as far
right as possible. Reference = +6 dBu.
5. SPECIFICATIONS
Mono inputs
Microphone inputs (IMP Invisible Mic Preamp)
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance -132.7 dB / 137 dB A-weighted
@ 50 Ω source resistance -130 dB / 133.9 dB A-weighted
@ 150 Ω source resistance -127.1 dB / 130.9 dB A-weighted
Frequency response <10 Hz - 200 kHz (-1 dB)
Gain range +10 to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx. 2.6 kΩ balanced
Signal-to-noise ratio -107 dB / -111 dB A-weighted
(0 dBu In @ +22 dB gain)
Distortion (THD+N) 0.005% / 0.003% A-weighted
Line input
Type 1/4" TRS connector
electronically balanced
Impedance approx. 20 kΩ balanced
10 kΩ unbalanced
Gain range -10 to +40 dB
Max. input level +20 dBu @ 0 dB Gain
Fade-out attenuation
1
(Crosstalk attenuation)
Main fader closed 85 dB
Channel fader closed 88 dB
Frequency response
Microphone input to main out
<10 Hz - 80 kHz +0 dB / -1 dB
<10 Hz - 137 kHz +0 dB / -3 dB
Stereo inputs
Type 1/4" TRS connector,
electronically balanced
Impedance approx. 20 kΩ bal. / 10kΩ unbal.
(+4 dBu operating level)
approx. 20 kΩ bal. / 5kΩ unbal.
(-10 dBV)
Max. input level +22 dBu
EQ mono channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
AUDIO OUTPUTS
FX send
Type 1/4" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Main outputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Control room outputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
5. SPECIFICATIONS
BEHRINGER is constantly striving to manintain the highest professional
standards. As a result of these efforts, modifications may be made from
time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
