7
The DSP Section:
The RFX65 features DSP
controls for Multi, Delay and
Reverb. Complete information
about the Multi and Delay
effects is given below. The Multi control selects the “pitch modified” and wah effects.
Many of these effects have their speed controlled by the Save/Tap button. The Delay
control selects the delay or echo effects. All of these effects have their speed controlled
by the Save/Tap button. Additional information is provided on pages 5 and 10.
REVERBREVERB
SAVE / TAPSAVE / TAP
MULTIMULTI
CHORUSCHORUS
FLANGEFLANGE
PHASERPHASER
VIBVIB
OO
TT
RR
DELAYDELAY
EFXEFX
ECHOECHO
SINGLESINGLE
TAPETAPE
DSPDSP
MULTI:
NAME DESCRIPTION SAVE/TAP BUTTON CONTROLS:
Chorus LO Chorus w/low depth speed: 1 cycle/tap - tap period: .05–1 second
Chorus MID Chorus w/medium depth speed: 1 cycle/tap - tap period: .05–1 second
Chorus HI Chorus w/high depth speed: 1 cycle/tap - tap period: .05–1 second
Flange LO Flanger w/low depth speed: 4 cycle/tap - tap period: .05–1 second
Flange MID Flanger w/medium depth speed: 4 cycle/tap - tap period: .05–1 second
Flange HI Flanger w/high depth speed: 4 cycle/tap - tap period: .05–1 second
Phaser LO Phaser w/low feedback speed: 2 cycle/tap - tap period: .05–1 second
Phaser MID Phaser w/medium feedback speed: 2 cycle/tap - tap period: .05–1 second
Phaser HI Phaser w/high feedback speed: 2 cycle/tap - tap period: .05–1 second
Vibrato LO Vibrato w/low depth speed: 1 cycle/tap - tap period: .05–1 second
Vibrato MID Vibrato w/medium depth speed: 1 cycle/tap - tap period: .05–1 second
Vibrato HI Vibrato w/high depth speed: 1 cycle/tap - tap period: .05–1 second
Octave Down Adds signal one octave lower n/a
Touch Wah Touch-sensitive wah-wah n/a
Reverse Wah Inverted wah-wah n/a
Bypass Dry signal - no effect n/a
DELA
Y:
NAME DESCRIPTION SAVE/TAP BUTTON CONTROLS:
Single LO Single delay w/low level time: .05–1 second
Single MID Single delay w/medium level time: .05–1 second
Single HI Single delay w/high level time: .05–1 second
Single MAX Single delay w/maximum level time: .05–1 second
Echo LO Echo w/low level time: .05–1 second
Echo MID Echo w/medium level time: .05–1 second
Echo HI Echo w/high level time: .05–1 second
Echo MAX Echo w/maximum level time: .05–1 second
Tape LO Tape echo w/low level time: .05–1 second
Tape MID Tape echo w/medium level time: .05–1 second
Tape HI Tape echo w/high level time: .05–1 second
Tape MAX Tape echo w/maximum level time: .05–1 second
Echo FX LO Echo w/low level, before multi effect time: .05–1 second
Echo FX MID Echo w/medium level, before multi effect time: .05–1 second
Echo FX HI Echo w/high level, before multi effect time: .05–1 second
Bypass Dry signal - no effect n/a
SIGNAL PATH FOR ECHO LO, MID & HI EFFECTS:
DELAY
SIGNAL PATH FOR ALL OTHER EFFECTS:
MULTI MULTI DELAY
Guitar Amplifier
