Specificationsandappearancearesubjecttochangewithoutnotice.
Specificationsandappearancearesubjecttochangewithoutnotice.
Technical Specifications
Note: Figures are typical values of 33M tape based on Fujifilm’s standard measurement procedures. The Figures marked with *
are comparisons with the Fujifilm reference tape.
Note: Figures are typical values based on Fujifilm’s standard measurement procedures.
The Figures marked with * are comparisons with the Fujifilm reference tape.
D5001 Technical Data
D421 Technical Data
Magnetic Properties
Physical Properties
Performance
Coercivity (Hc) 127.3 kA/m
Retentivity (Br) 265 mT
Thickness: Magnetic Layer 3.1 µm
: Total 13.5 µm
Tape Width 12.65 mm
Yield Strength 27 N
Breaking Tensile Strength 39 N
Residual Elongation Less than 0.18 %
Video RF Output 0 dB*
Video C/N 0 dB*
Audio Sensitivity 0 dB*
Audio Frequency Response 0 dB*
Magnetic Properties
Physical Properties
Performance
Coercivity (Hc) 147.2 kA/m
Retentivity (Br) 310 mT
Thickness: Magnetic Layer (Upper Layer) 0.7µm
: Non-Magnetic Layer (Lower Layer) 2.3 µm
: Total 14.4 µm
Tape Width 12.65 mm
Yield Strength 22 N
Breaking Tensile Strength 43 N
Residual Elongation Less than 0.2 %
Video RF Output 0 dB*
Video S/N 0 dB*
Audio Sensitivity 0 dB*
Audio Frequency Response 0 dB*
CD-R Printable Technical Data
Basic Specifications
Physical Characteristics
Operating Environment
Linear Velocity 1.2 m/s
Substrate Material Polycarbonate
Recording Layer Organic Dye
Outer Diameter 120.0 mm
Inner Diameter 15.0 mm
Thickness 1.2 mm
Temperature -5 ~ 55 °C
Humidity 3 ~ 95 % RH (No dew condensation)
Note:Figures are typical values based on Fujifilm’s standard measurement procedures.
Note: Figures are typical values based on Fujifilm’s standard measurements on S-VHS format.
The figures marked with * are comparisons with the Fujifilm H471S reference tape.
H471S Technical Data
DVD-R 8x Printable Technical Data
Magnetic Properties
Physical Properties
Performance
Coercivity (Hc) 76 kA/m
Tape Thickness: Total 17.5µm
Tape Width 12.65 mm
Yield Strength 26 N
Video RF Output + 3.0 dB*
Video S/N + 1.5 dB*
Audio HiFi Output + 3.5 dB*
Basic Specifications
Physical Characteristics
Operating Environment
Capacity 4.7GB
Linear Velocity 3.49 m/s (1x), 27.92 m/s (8x)
Substrate Material Polycarbonate
Recording Layer OrganicDye
Recording Wavelength 650 nm
Outer Diameter 120.0 mm
Inner Diameter 15.0 mm
Thickness 1.2 (0.6 x 2) mm
Temperature -5 ~ 55 °C
Humidity 3 ~ 95 % RH(No dew condensation)
(*1) When the disc is used in PDW-1500 Compact Studio Recorder, some function operaters at higher data rate if latest software
is used.
(*2) Since a portion of user data area will be used for data management, available capacity may vary.
"Professional Disc", "XDCAM", "DVCAM" and "MPEG IMX" are trademarks of Sony Corporation.
PD711 Technical Data
PD711 Recording Time (*2)
Approx. 60 min. (HQ mode)
HD MPEG HD Approx.90 min. (SP mode)
Approx. 120 min. (LP mode)
SD
MPEG IMX Approx. 45 min. (50 Mbps)
MPEG IMX Approx. 85 min. (50 Mbps)
Basic Specifications
Physical Characteristics
Disc Type Rewritable
Capacity 23.3GB
Recording Wavelength 405 nm (Blue-Violet Laser)
Recording Method Phase Change Recording
DataTransferRate 72or 86(*1) Mbpswith1Optical Head,144or172(*1)Mbpswith2 OpticalHeads
Track Pitch 0.32 µm
No. of Read Over 1,000,000 times
Estimated Shelf Life 50 years or more
Estimated Archival Life 50years or more
Operating Condition -5 ~ 55 °C, 3 ~ 90 % RH
Storage Condition -10 ~ 55 °C, 5 ~ 90 % RH
Disc Diameter 120.0 mm
Disc Thickness 1.2mm
Cover Layer Thickness 0.1mm
Cartridge Dimension 128.6 x 130.6 x 9.1 mm
