1. Unscrew the outside FADER PLATE SCREWS (B). Do not
touch the INSIDE SCREWS (C).
2. Carefully lift the fader and unplug the CABLE (D).
3. Plug the new fader into the cable and place it back in the
mixer.
4. Screw the fader to the mixer.
5. BEAT INDICATORS: Each side of the CROSSFADER (25) has its own
BEAT INDICATOR (23, 24). They flash at the low frequency peak
level allowing you to match the beats visually. BEAT INDICATOR
(23) will reflect the beat of the left side of the CROSSFADER (25)
and BEAT INDICATOR (24) will do the same for the right side.
6. OUTPUT CONTROL SECTION: The level of the AMP OUT (38) is
controlled by the MASTER (18) control. The BALANCE (17) control
will allow the Amp Out signal to be balanced between the left and
right speakers. The BOOTH (16) control adjusts the level of the
BOOTH OUTPUT (39). HINT: The booth OUTPUT is used by some
DJs to run monitor speakers in their DJ booth. You can also use it as
a second ZONE or AMP output.
NOTE: The RECORD OUT (40) has no level control.
The level is set by the channel slides and the gain
controls of the selected channel. The tonal qualities are
set by the bass, treble and mid controls of that same
channel.
7. TALKOVER SECTION: The purpose of the talkover section is to allow
the program playing to be muted so that the mic can be heard above
the music. When the TALKOVER (19) button is pushed, the
TALKOVER INDICATOR (28) will glow and the volume of all
sources except the Mic or whatever is connected to the PHONO/
LINE (36) input are reduced by -16 dB.
8. CUE SECTION: By connecting a set of headphones to the
HEADPHONE (4) jack, you can monitor any or all of the channels.
Select the correct CUE (21) button or buttons and their respective
CUE LED (29) indicators will glow. Use the CUE LEVEL (20) control
to adjust the headphone volume without effecting the overall mix. By
sliding the CUE PGM PAN (22) control to the left you will be able to
monitor the assigned cue signal. Sliding to the right will monitor the
PGM (program) output.
9. DISPLAY: The peak hold, dual function DISPLAY (26) indicates either
the MASTER (38) output left and right levels or the channel 2 and
channel 3 levels. You can choose the option you want by pressing
the DISPLAY (27) button.
NOTE: When the DISPLAY (27) is in the channel 2/
channel 3 display mode, by adjusting the individual
channel gain and tone controls, you can increase or
decrease the signal to match the other channels signal.
The channel slides and crossfader have no effect on the
display readings.
Specifications
INPUTS:
DJ Mic....................................................1.5mV 2Kohm unbalanced
Phono.........................................................................3mV 47Kohm
Line.......................................................................150 mV 27Kohm
OUTPUTS:
Amp/Booth......................................................0 dB 775mV 400ohm
Max..............................24V Peak to Peak
Rec...........................................................................225mV 5Kohm
GENERAL:
Bass...........................................................................+ 12 / -32dB
Mid............................................................................+ 12 / -32dB
Treble..........................................................................+ 12 / -32dB
Gain (Mic)........................................................................0 to -40dB
Gain (Chnls 1-3)..............................................................0 to -20dB
Frequency Response....................................20Hz - 20KHz +/- 2dB
Distortion................................................................................0.02%
S/N Ratio...............................................................better than 80dB
Talkover Attenuation..............................................................-16dB
Headphone Impedance.........................................................16ohm
Power Source.............................................115/230V 50/60Hz 15W
Dimensions...........................................254mm x 305mm x 112mm
10" x 12" x 4 7/16"
Weight........................................................................6.5 lbs (3 Kg)
