Page 6
tracks with similar Beats Per Minute, you can use one source’s pitch
control to align the Beats Per Minute with the other source’s BPM. The
BPM DISPLAY and the BEAT OFFSET INDICATORS update every 2.5
seconds and will reflect the change in BPM and indicate when the
beats are aligned.
NOTE: Beat mixing is a skill that requires practice. Not every
track has a strong beat, and beat mixing works best with
tracks with tracks with clear and strong beats.
SPECIFICATIONS
INPUTS:
Phono @ 1kHz.......................................................................2mV 47 kΩ
Line...............................................................................100 mV 10 kΩ
MIC 1 , MIC 2 & MIC 3....................................................1.5mV 2 KΩ Balanced
OUTPUTS:
Main/Aux.......................................................................0 dB 1V 400 kΩ
Max...............................................................................20V Peak-to-Peak
Rec..................................................................................225mV 5 kΩ
GENERAL:
Low (Channels 1-4).............................................................+ 12dB/- 32 dB
Mid (Channels 1-4)...............................................................+ 12dB/- 32 dB
High (Channels 1-4).............................................................+ 12dB/- 32 dB
Gain (Channels 1-4).......................................................................0 to -20dB
Bass (MIC1 , MIC2).......................................................................± 12dB
Treble (MIC1 , MIC2).......................................................................± 12dB
Frequency Response............................................20Hz - 20kHz +/- 2dB
Distortion................................................................................less than 0.02%
S/N Ratio..........................................................................better than 80dB
Talkover Attenuation........................................................................16dB
Power Source...................................................115/230V 50/60Hz 20W
Dimensions....................................................................19”W x 4”H x 9”D
Weight........................................................................................10 lbs
