Technical Data
ew 100 g
Modulation wideband FM
Frequency ranges 516-558, 566-608, 626-668, 734-776, 780-822, 823-865
Transmission/Receiving frequencies 20 channel banks, 1 xed bank, 12 factory preset channels each
Switching bandwidth 42 MHz
Noise reduction system Sennheiser HDX
AF frequency response 25 – 18.000 Hz
S/N ratio (at 1mV and peak deviation) ≥ 110 dBA
THD (at nominal deviation and 1 kHz) ≤ 0,9 %
SK 100 g
EK 100 g
RF output power at 50 typ. 30mW
AF frequency response 25 – 18.000 Hz (Line)
Max input voltage transmitter / line 3 V
eff
Input impedance transmitter / line 40 kO, unbalanced / 1MO
Power supply 2 AA batteries, 1.5 V
Nominal voltage 2.4 V
Operating time typ. 8h
Dimensions 82 x 64 x 24 mm (3.23" x 2.52" x 0.94")
Weight approx. 160 g (5.64 oz)
Receiver principle Diversity
Sensitivity (with HDX, peak deviation) <2,5 µV at 52 dBA
eff
S/N
Adjacent channel rejection ≥ 65 dB
Intermodulation attenuation ≥ 65 dB
Blocking ≥ 70 dB
Pilot-tone squelch detachable
AF output voltage (at peak deviation, 1kHz AF) 3.5 mm jack socket, unbalanced: +12 dBu
Power supply 2 AA batteries, 1.5V
Dimensions approx. 82 x 64 x 24 mm (3.23" x 2.52" x 0.94")
Weight approx. 160 g (5.64 oz) (incl. batteries)
Operation time typ. 8h
Variants and scope of supply
• ew 100 ENG g with SK 100 g bodypack transmitter, SKP 100 g plug-on transmitter, ME 2 clip-on microphone
• ew 112-p g with SK 100 g bodypack transmitter and ME 2 clip-on microphone
• ew 122 g with SK 100 g bodypack transmitter and ME 4 clip-on microphone
• ew 135-p with EK 100 g bodypack receiver and SKM 135 g handheld transmitter, MZQ 1 microphone clip
For recommended accessories please visit www.sennheiser.com
ew 100 ENG ew 112-p ew 122-p ew 135-p
