vv : Value
cc Control Value [vv]
08H Dual Balance 00H : Left Voice Max.
7FH : Right Voice Max.
26H Touch Sensitivity 00H : Medium
01H : Soft
02H : Hard
58H Brilliance 00H : Normal
01H : Mellow
02H : Bright
59H Reverb 00H : Off
01H : Room
02H : Hall-1
03H : Hall-2
04H : Cosmic
5AH Dual Mode 00H : Dual Off
01H : Dual On (Normal)
02H : Dual On (Left voice 1 octave up)
03H : Dual On (Right voice 1 octave up)
5CH Dual Voice [vv] : Dual Voice
PANEL DATA SEND FORMAT
F0H, 43H, 0nH, 7CH, 00H, 19H (n: channel number)
53H, 4BH, 20H, 20H (SK)
43H, 4CH, 50H, 31H, 32H, 33H (CLP-123)
3xH, 3yH (x, y: version number)
[PANEL DATA]
[CHECK SUM (1byte)] = 0-(53H+4BH+20H+......+Data end)
F7H
• Panel Data Contents
(1) VOICE
(2) DUAL VOICE
(3) DUAL ON/OFF
(4) DUAL BALANCE
(5) BRILLIANCE
(6) 0
(7) 0
(8) REVERB NUMBER
(9) REVERB DEPTH
(10) TOUCH SENSITIVITY
(11) 0
(12) SPLIT POINT
(13) 0
MODEL ID CODE SEND FORMAT
F0H, 43H, 0nH, 7DH, 00H, 10H (n: channel number)
53H, 4BH, 20H, 20H (SK)
43H, 4CH, 50H, 31H, 32H, 33H (CLP-123)
3xH, 3yH, 20H, 20H, 20H, 20H (x, y: version number)
[CHECK SUM (1byte)] = 0-(53H+4BH+20H+......+20H)
F7H
CLP-123
KEYBOARD 88 KEYS (A-1 ~ C7)
VOICE SELECTORS PIANO1, PIANO2, CLAVINOVA TONE, E. PIANO, HARPSICHORD, VIBES,
STRINGS, ORGAN
BRILLIANCE MELLOW, NORMAL, BRIGHT
REVERB ROOM, HALL 1, HALL 2, COSMIC
TOUCH SENSITIVITY HARD, MEDIUM, SOFT
PEDAL CONTROLS SOFT, SOSTENUTO, DAMPER
OTHER CONTROLS MASTER VOLUME, MIDI/TRANSPOSE
JACKS/CONNECTORS HEADPHONES x 2, AUX. OUT R & L/L+R, OPTIONAL IN R/L, MIDI IN/OUT/
THRU
INPUT & OUTPUT AUX. OUT: 600Ω
LEVEL/IMPEDANCE OPTIONAL IN: 22kΩ/-10 dBm (for nominal output level)
MAIN AMPLIFIERS 30W x 2
SPEAKERS 13 cm x 2, 5 cm x 2
DIMENTIONS (W x D x H) 1439.8 x 469.4 x 832.2 mm (56-3/4" x 18-1/2" x 32-3/4")
WEIGHT 59.0 kg (130.0 lbs.)
Specifications/Technische Daten/Caractéristiques techniques/Especificaciones
* Specifications subject to change without notice.
* Änderungen ohne Vorankündigung vorbehalten.
* Sous toute réserve de modification des caractéristiques sans préavis.
* Especificaciones sujetas a cambios sin previo aviso.
