SYSTEM STATUS > ETHERNET PORT > I/F STATUS
Read security: 5
Indicates the current status of the ETHERNET port.
SYSTEM STATUS > ETHERNET PORT > TX FRAMES
Read security: 5
Indicates the number of frames transmitted from the ETHERNET port since system startup.
SYSTEM STATUS > ETHERNET PORT > RX FRAMES
Read security: 5
Indicates the number of frames received on the ETHERNET port since system startup.
SYSTEM STATUS > ETHERNET PORT > ETHERNET RATE
Read security: 5
Indicates whether the Ethernet network is 10 or 100BaseT.
SYSTEM STATUS > CHAIN PORT
Write security: 2; Read security: 5
Displays the status of the RJ-45 (female) CONTROL IN (Chain) port.
SYSTEM STATUS > CHAIN PORT > SIGNAL LEADS
Read security: 5
Displays the state of the CONTROL IN (Chain) port signals (RTS, CTS, DTR, and DCD).
SYSTEM STATUS > CHAIN PORT > TX BYTES
Read security: 5
Displays the number of bytes transmitted from the CONTROL IN (Chain) port.
SYSTEM STATUS > CHAIN PORT > RX BYTES
Read security: 5
Displays the number of bytes received by the CONTROL IN (Chain) port.
SYSTEM STATUS > CHAIN PORT > OVERRUN ERRS
Read security: 5
Displays the number of overrun errors received by the CONTROL IN (Chain) port.
SYSTEM STATUS > CHAIN PORT > FRAMING ERRS
Read security: 5
Displays the number of framing errors received by the CONTROL IN (Chain) port.
