Description
Drive units
Frequency range
Frequency response
Dispersion
Sensitivity
Harmonic distortion
Nominal impedance
Crossover frequency
Power handling
Max. recommended
cable impedance
Dimensions
Net Weight
DM
™
601 S2
Kevlar is a registered trademark of Dupont.
B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments.
Copyright © B&W Loudspeakers Ltd. Printed in England.
B&W Loudspeakers Ltd, Meadow Road, Worthing, BN11 2RX Tel: +44 (0) 1903 524801 Fax: +44 (0) 1903 524725
http://www.bwspeakers.com
2-way 4th-order vented-box system
1x 165mm (6.5in)
woven Kevlar
®
cone bass/mid
1x 26mm (1in)
metal dome high-frequency
-6dB at 50Hz and 30kHz
70Hz - 20kHz ± 3dB on reference axis
Within 2dB of response on reference axis
Horizontal: over 40° arc
Vertical: over 10° arc
88dB spl (2.83V, 1m)
2nd & 3rd harmonics
<1% 88Hz - 20kHz (90dB spl, 1m)
8 Ω (minimum 4.3 Ω)
4kHz
25W-100W continuous into
8 Ω on unclipped programme
0.1 Ω
Height: 356mm (14 in)
Width: 204mm (8 in)
Depth: 244mm (9.6 in)
6.1kg (13.4 lb)
I 4919 Issue 1
DM
™
602 S2
2-way 4th-order vented-box system
1x 180mm (7in)
woven Kevlar
®
cone bass/mid
1x 26mm (1in)
metal dome high-frequency
-6dB at 43Hz and 30kHz
52Hz - 20kHz ±3dB on reference axis
Within 2dB of response on reference axis
Horizontal: over 40° arc
Vertical: over 10° arc
90dB spl (2.83V, 1m)
2nd & 3rd harmonics
<1% 60Hz - 20kHz (90dB spl, 1m)
8 Ω (minimum 4.3 Ω)
4kHz
25W-120W continuous into
8 Ω on unclipped programme
0.1 Ω
Height: 490mm (19.3 in)
Width: 236mm (9.3 in)
Depth: 306mm (12 in)
9.8kg (21.6 lb)
