EURORACK UB1222FX-PRO
UB1222FX-PRO
EURORACK
Ultra Low-Noise Design 16-Input Mic/Line Mixer with Premium Mic Pre-
amplifiers, FBQ Feedback Detection System and 24-Bit Multi-FX Processor
s Ultra low-noise ULN design, highest possible headroom, ultra-transparent audio
s 4 new state-of-the-art, studio-grade IMP Invisible Mic Preamps with:
- 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs
- Ultra-wide 60 dB gain range
- Lowest possible distortion 0.0007% (20 Hz - 20 kHz)
s Revolutionary, patent-pending FBQ Feedback Detection System instantly reveals critical frequencies
s Integrated 24-bit digital stereo FX processor with 99 great-sounding VIRTUALIZER presets including
reverb, delay, chorus, compressor, tube distortion, vinylizer and more plus 1 kHz test tone generator
s Voice Canceller function on dedicated CD/tape return channel for easy-to-use sing-along applications
s Breathtaking XPQ 3D stereo surround effect for more vitality and enhanced stereo image
s 7-band stereo graphic EQ allows precise frequency correction of monitor or main mixes
s 4 fully equipped stereo input channels featuring 2 additional mic inputs on channels 5/6 and 7/8, 3-band
EQ and input trim control
s Effective, extremely musical 3-band EQ plus switchable low cut filter on all mono channels
s Inserts on each mono channel for flexible connection of outboard equipment
s 12 high-headroom line inputs
s Standby-switch mutes all mic channels during breaks while background music is provided via CD/tape or
line inputs
s State-of-the-art 4580 operational amplifiers provide lowest noise and distortionbetter than 4560 op
amps
s 2 aux sends per channel: 1 pre fader for monitoring, 1 post fader (for internal FX and/or as external send)
s Clip indication and gain level set LEDs plus mute switches for each channel allow fast and accurate level
setting
s 2 multi-functional stereo aux returns
s Balanced main mix outputs with gold-plated XLR connectors, headphone/control room output and stereo
tape outputs
s Switchable +48 V phantom power for condenser microphones
s Long-wearing 60-mm logarithmic-taper ALPS
®
faders and sealed rotary controls
s Internal switch-mode power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior
transient response plus lowest possible power consumption for energy saving
s Extremely rugged steel construction ensures long life even under most demanding conditions
s Rack mount brackets included
s Designed in Germany. Manufactured under ISO9001 certified management system
