ULTRA-GRAPH PRO GEQ3102
5. SPECIFICATIONS
AUDIO INPUT
Connectors XLR and 1/4" jack
Type RF filtered, servo-balanced input
Impedance 50 kOhm balanced, 25 kOhm unbalanced
Max. input level +21 dBu balanced and unbalanced
CMRR typ. 40 dB, > 53 dB @ 1 kHz
AUDIO OUTPUT
Connectors XLR and 1/4" jack
Type electronically servo-balanced output stage
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. output level +21 dBu balanced and unbalanced
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 35 kHz, +/- 3 dB
Noise > 92.3 dBu, unweighted, 22 Hz to 22 kHz
THD 0.004 % typ. @ +4 dBu, 1 kHz, Gain 1
Crosstalk < -85 dB, 22 Hz to 22 kHz
ROLL-OFF FILTER SECTION
Type 12 dB/oct., butterworth
Input variable (-15 dB to +15 dB)
Low cut variable (10 Hz to 400 Hz)
High cut variable (2.5 kHz to 30 kHz)
GRAPHIC EQUALIZER
Type analog 1/3-octave equalizer
Frequency range 20 Hz to 20 kHz in 31 1/3-octave bands (ISO frequencies)
Bandwidth 1/3 octave
Control range +/- 6 dB or +/- 12 dB (switchable)
FUNCTION SWITCHES
Audio in/out switch to bypass the equalizer functions
I/O meter in/out switches the meter display from input to output
Range shift of the maximum cut/boost range for all 31 bands
INDICATORS
Input/output level 12-segment LED display: -30/-24/-18/-12/-6/-3/0/+3/+6/+9/+12/+18 dB
Function switch LED indicator for every switch
POWER SUPPLY
Mains voltages USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General export model 100-120 V ~, 200-240 V ~, 50-60 Hz
Power consumption approx. 20 Watts
Fuse 100-120 V ~: T 400 mA H
200-240 V ~: T 200 mA H
Mains connection standard IEC receptacle
PHYSICAL
Dimension approx. 3,5" (89 mm) * 19" (482.6 mm) * 5.3" (135 mm)
Weight approx. 2.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from
time to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
