Installation
2-8
Installing the Module into the SmartSwitch 9000
Chassis
To install the 9G421-02/9G429-02 module into the SmartSwitch 9000 chassis,
follow these steps:
1. Remove the blank panel covering the slot in which you will install the
module. If you are only installing one module, make sure the other module
slots are covered. This action ensures proper airßow and cooling.
2. Attach one end of the ESD wrist strap (packaged with the SmartSwitch 9000
chassis) to your wrist. Plug the other end into the ESD Wrist Strap grounding
receptacle in the lower right corner of the SmartSwitch 9000 chassis shown in
Figure 2-5.
3. Grasp the module and slide it into the slot. Make sure that the moduleÕs
circuit card is between the card guides, as shown in Figure 2-5. Check both the
upper and lower tracks of the card. Make sure that the module slides in
straight and engages the backplane connectors properly.
4. Lock down the top and bottom plastic tabs, as shown in Figure 2-5.
To insure proper data transmission from the 9G421-02/9G429-02 module to the
INB on the SmartSwitch 9000 backplane, two INB Terminator modules must be
installed on the rear of the SmartSwitch 9000 chassis. If they have not previously
been installed, refer to the INB Terminator Module Installation Guide for
information and installation procedure.
NOTE
