Appendix A: WPIM Cable Specifications
A-14 CSX200 Installation Guide
WPIM-DI
This section provides Cabletron Systems part number and connector speciļ¬cations for the
WPIM-DI interface cables.
Table A-22 shows the connector number, cable assembly description, cable and interface type,
connector type and part number information for the WPIM-DI interface.
Table A-23 provides the WPIM-DI network interface cable pin assignments.
Table A-22 WPIM-DI Connector Information
Connector
Number
Cable Assembly Description
Cable and
Interface Type
Connector
Type
Part Number
1 Network
DI RJ48 9372094
2 Drop and Insert
Table A-23 WPIM-DI Network
Pin Signal
1 Receive Ring
2 Receive Tip
3 AC Coupled Ground
4 Transmit Ring
5 Transmit Tip
6 AC Coupled Ground
7 AC Coupled Ground
8 AC Coupled Ground
