INSTALLATION REFERENCE
EATON Powerware
®
9315 UPS (500–750 kVA) Installationand Operation Manual S 164201691 Rev 1 www.powerware.com
A-19
14. External overcurrent protection is not provided by this product, but is required
by codes. See Table E through Table G starting on page A-13 for w iring
requirements. If an output lockable disconnect is required, it is to be supplied
by designated personnel.
15. Table K lists the maximum rating for continuous duty rated input circuit
breakers.
CAUTION
To reduce the risk of fire, connect only to a circuit provided with maximum input circuit breaker current
ratings from Table K according to the NEC, ANSI/NFPA 70.
Table K. Maximum Input Circuit Breaker Ratings
Input Voltage Rating
UPS Model
400V 480V 600V
PW9315-625/400
PW9315-625/450
1000A N/A N/A
PW9315-625/500
PW9315-625/562
1200A N/A N/A
PW9315-750/500
PW9315-750/562
N/A 1000A 800A
PW9315-750/600
PW9315-750/675
N/A 1200A 1000A
16. Source protection for the AC input should be treated as if you were supplying a
750 kVA three-phase transformer, to allow f or inrush current.
17. The input breaker (CB1) has a trip rating of 1200 amps AT and a standard
ampere interrupting capacity (AIC) of 65,000 in symmetrical RMS amps. An
optional 100,000 AIC breaker is available.
18. The input and bypass three-phase feeds should be symmetrical about ground,
due to the existence of voltage surge protection devices.
19. The line-to-line unbalanced output capability of the UPS is limited only by the
full load per phase current values for AC output to critical load shown in
Table E through Table G. The recommended line-to-line load unbalance is 50%
or less.
20. Output overcurrent protection and output disconnect switch are to be provided
by the user. Table L lists the maximum rating for continuous duty rated output
circuit breakers satisfying the criteria for both.
