- 14 -
General
Power voltage 12VDC
Power consumption 9VA
Outside dimensions <Unfolded> 361mm(W)x282mm(D)x161-284mm(H)
(14.2in.(W)x11.1in.(D)x6.3-11.2in.(H))
<Folded> 59mm(W)x282mm(D)x161mm(H)
(2.3in.(W)x11.1in.(D)x6.3in.(H))
Mass 1.5kg (3.3lbs)
Optical
Lens F: 2.9, f= 3mm
Shooting area <Max.> 364mmx271mm (14.3in.x10.7in.)
<Min.> 179mmx135mm (7.1in.x5.3in.)
Camera
Image pick-up element Progressive square picture element 1/3"size CCD
Image pick-up speed 20 frames/sec
Total picture elements 1077(H)x788(V) . . . 850,000 pixels
Effective picture elements 1024(H)x768(V)
Resolution 600 TV lines or more (Horizontal)
600 TV lines or more (Vertical)
Sync. signal frequency 48.363kHz (Horizontal)
60.004Hz (Vertical)
Output signal Analog RGB, 1024x768 at 60Hz, compliant with VESA
Digitalzoom 4x
White balance Full auto/Lock
Gamma adjustment Provided (3-position selection switch)
Gain adjustment Provided (UP/DOWN pushbutton switch)
Ext. input selection Provided (Main camera / Ext. selection switch)
Ext. input terminal D-sub 15-pin (Analog RGB signal) 1 pc
Output terminal D-sub 15-pin (Analog RGB signal) 1 pc
Supplied accessories
Accessory case 1pc
Analog RGB cable (Mini DSUB 15P connector) 1pc
AC adaptor 1pc
Instruction manual 1pc
Warranty card 1pc
These specifications are subject to change without prior notice.
Trademark Acknowledgements
, ELMO are registered trademarks of ELMO CO., Ltd.
VESA is a resistered trademark of Video Electronics Standards Association.
FOCUSFREE is a trademark of ELMO CO., Ltd.
4. SPECIFICATIONS
