Flame failure reignition system
In the event of the flame being accidentally blown out, the flame failure reignition system will
detect this, and the electrode will spark and relight the flame. If no flame is detected after about
five seconds, the gas supply to the appliance will be shut off and the burner ‘ON’ indicator light
will flash slowly. The burner must be turned OFF and restarted to resume cooking.
Power failure
In the event of a power failure, the gas supply will be cut off, even if a burner is in use. When the
power is restored and if the burner control knob is still in the ON position, the burner ‘ON’ light
will flash rapidly. The burner must be turned OFF and restarted to resume cooking.
Accessories
Using a wok
The pan support over the central ‘wok’ burner is shaped to fit a wok. Care should be taken when
using a large wok that other pots are not pushed sideways and become unstable or deflect heat
onto nearby walls.
Re-assembling the wok burner (CG913TM Iridium models only)
Parts of your wok burner have locating pins to help you to assemble it correctly after cleaning.
Incorrect assembly can cause irregular flames and ignition problems. Refer to this diagram for
the correct order of assembly. Note: The brass parts of your wok burner will change colour with
use. This is normal and will not affect performance.
Rotate burner ring to align
locator pin with hole in burner
base.
Side view
TITAN MODELS (CG913 Series)
Inner cap
Burner cover (small holes)
Decorative ring
Burner ring with locator pins
(large holes)
Align and insert pin
4
