3307568 User’s Manual Hardware Setup
Connector: CN_12V
Type: 8-pin ATX power connector
PIN assignment
1 GND 5 +12V
2 GND 6 +12V
3 GND 7 +12V
4 GND 8 +12V
Connector: DC_IN
Type: 4-pin P-type connector for +5V/+12V input
Pin Description Pin Description Pin Description Pin Description
1 +12V 2 Ground 3 Ground 4 +5V
Connector: CN_PS
Type: 3-pin ATX function connector
Pin Description Pin Description Pin Description
1 5V Standby 2 Ground 3 Power On
Connector: CPUFAN
Type: 4-pin fan wafer connector
Pin Description Pin Description
1 Ground 2 +12V
3 Fan Speed Detection 4 Fan Control
Connector: NBFAN, SYSFAN
Type: 3-pin fan wafer connector
Pin Description Pin Description Pin Description
1 Ground 2 +12V 3 Sense
Power and Fan Installation 31
