30
ITEM NO. PART NO. DESCRIPTION QTY
1 31301227-3 Deck 1
2 34106236 Rear enclosure 1
3 32201235 Screw 6
4 3410438-1 Side discharge chute 1
5 31107227 Side discharge cover assy. 1
5-1 3410338-2 Side discharge cover 1
5-2 3320338 Side discharge axle 1
5-3 3420207 Rubber bushing 2
5-4 3340237 Spring 1
5-5 3330637 Side discharge bracket 1
5-6 3220136 Bolt 2
6 33305222-2 Height adjustment plate(R) 1
7 3410137 Cord guide 1
8 3221137 Screw 2
9 3410403 Cord clip 1
10 3220346 Screw 2
11 33304235 Spring for rear cover (L) 1
12 3320138-1 Axle for rear cover 1
13 34103236-2 Rear cover 1
14 3220511 Screw 1
15 3220850 Screw 2
16 3410290-1 Resistance clamp 1
17 3220439 Nut 2
18 3220951 Screw 2
19 33302235 Spring for rear cover (R) 1
20 3420436 Spring bushing 2
21 3290506 Clip 1
22 3331035 Resistance heat radiator 1
23 3290105 Nut 1
24 3290675 Spring washer 1
25 36901227 Resistor & bracket 1
26 3331035 Rectier heat radiator 1
27 3610138-1 12 A motor assy. 1
27-1 3110638-3 Brush 2
28 32205227 Bolt 1
29 3690135 Rectier (KBPC2504) 1
30 3220404 Screw 1
31 34103222-1 Motor cover 1
32 3420235 Cover seal 1
33 34105222-3 Motor vent 1
34 3220435 Screw 4
PARTS LIST
