LOWER MAINFRAME
PARTS
LIST
49 SHAFT ROLLER WELDED 111-0589 1
50 SHROUD-FREEWHEEL 340168 1
51 SPRING COUNTER BALANCE 410050 1
52 SPRING TORSION HOC GALV 480132 1
53 SPRING VARIATOR HY412004 1
54 SPROCKET GEARBOX 10T*3/8 411011 1
55 SPROCKET ROLLER 18T*3/8 411010 1
56 THROWPLATE 111-0218 1
57 UNDERDECK CHUTE 111-0131 1
58 UNDERDECK COVER 111-0133 1
59 PULLEY VARIATOR ASSY 411001 1
60 WASHER PLAIN 5/16*1*16G 09270 1
61 WASHER PLAIN M6 09472 2
62 SCREW SOC SHOULDERED ZIS8L0305 1
63 WASHER STARLOCK 5/16" 0201086 2
64 WHEEL WITH BEARINGS HY5218 2
65 NUT M10 NYLOC ZNN1J000U 1
66 CLUTCH LEVER 411020 1
67 CLUTCH SPRING 411021 1
68 PULLEY 411019 1
69 PIN 411023 1
70 BELT VARIATOR 450 411025 1
71 BRACKET BBC W/A 111-0180 1
72 SCREW SOC. HD BUTTON 111-0717 2
73 SPACER CUTTERBAR BBC 111-0707 2
74 SCREW TAPTITE UNC 3/8*1 1/4 09349 2
75 NIPPLE SPLIT 510118 1
1.35
ITEM NO.
QTY.
493
DESCRIPTION
PART NO.
ITEM NOTE
111-0761(A) 31/3/06 10:46 am Page 1.35
