IU 688 / 0402 8 TowerFeed
TM
for the HP color LaserJet 4650
INSTALLATION
Electrical and Data Connetion
Without Stacker
Connect printer and TowerFeed with the data cable (Fig. 10): one
end with the printer and the other end with TowerFeed. Use the
provided Adapter as a intermediate piece.
Connect the power cables to printer and TowerFeed .
Note:
Power ON TowerFeed before or simultaneously with the printer.
Caution:
Only move TowerFeed to another place with drawers closed
and without printer on top to avoid hazard of toppling. Drawers
need to be secured against unintentional opening. Be careful
when crossing doorsteps or different flooring materials.
Fig. 10
Power socket position
Data Cabel
Fig. 11
Power Switches
