HP EliteBook 8740w ENERGY STAR on HP websites and on
www.energystar.gov
.
** EPEAT TBD Registered in U.S. EPEAT registration varies by country. See
www.epeat.net
for
registration status by country.
NOTE:
For accessibility information on HP products, please visit:
http://www.hp.com/accessibility
.
HP 230W Slim Smart
AC Adapter
Dimensions
20.0 x 10.0 x 4.0 cm (7.87 x 3.94 x 1.57 in)
Weight
1300 g (2.87 lb)
Input
100 to 240 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
3.5 A at 90 VAC, 1.75 A at 180 VAC
Output
Output power
230W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<18A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
0° to 35° C (32° to 104° F)
Non-operating (storage)
temperature
-20° to 65° C (-4° to 149° F)
Altitude
0 to 3,048 m (0 to 10,000 ft)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark- full compliance with LVD and EMC directives; Worldwide
safety standards- IEC950, EN60950, UL1950, Class 1, SELV; Agency
approvals- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC
Class B, CISPR22 Class B, CCIB, NOM-1 NYCE; MTBF- over 200,000
hours at 25°C ambient condition.
HP 200W Slim Smart
AC Adapter
Dimensions
17.0 x 8.5 x 3.5 cm (6.69 x 3.35 x 1.38 in)
Weight
920 g (2.03 lb)
Input
100 to 240 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
2.9 A at 90 VAC, 1.45 A at 180 VAC
Output
Output power
200W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<16A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
0° to 35° C (32° to 104° F)
Non-operating (storage)
temperature
-20° to 65° C (-4° to 149° F)
Altitude
0 to 3,048 m (0 to 10,000 ft)
Humidity
20% to 80%
QuickSpecs
HP EliteBook 8740w Mobile Workstation
Technical Specifications
DA - 13543 Europe, Middle East and Africa QuickSpecs — Version 5 — 5.26.2010
Page 19
