QuickSpecs
HP Compaq nx6310 Notebook PC
Technical Specifications
DA – 12432 EMEA — Version 10 — June 27, 2006 Page 18
Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor -110 dB
Play/Record Sampling
Rate(s)
8 kHz– 48 kHz
Audio Output Quality
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
Power Rating 2 Watts Internal Speaker
Impedance 4 Ohms
Communications
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses
21-30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Manageability Wake-on-LAN from standby and hibernation (configurable; Magic Packet
and Microsoft Wake-Up Frame)
PXE 2.1 Remote Boot
Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Interface 32-bit PCI, 33-MHz
NIC Device Driver Name Broadcom 440X 10/100 Integrated Controller
Integrated Broadcom
10/100 Ethernet PCI
Controller (BCM4401)
Drivers Available Microsoft Windows XP
Microsoft Windows 2000
Form Factor MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC
Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian
ACA, CE Mark, Other Countries
V.92 data
V.8bis
V.92 56K Data/Fax
Modem
Data Mode Capabilities
V.80
