Thank you for purchasing a JET pallet truck. Your pallet truck is made of high quality steel and
was designed to give you a durable, reliable and easy to use product. With proper maintenance,
your JET pallet truck will give you years of trouble free operation.
WARRANTY POLICY
Your JET pallet truck is backed by a nationwide network of distributors and authorized repair
stations. It is guaranteed to be free from defects in materials and workmanship. JET pallet trucks that
fail during the first year of operation due to such defects will be repaired or replaced at our discretion.
Normal wear and tear on moving parts and seals is excluded from this guarantee.This guaratee does
not apply to any product showing signs of misuse, overloading, alteration, or improper maintenance.
WARRANTY PROCEDURE
After receiving authorization from one of our offices, any product for which there is a warranty
claim must be returned prepaid to an authorized warranty depot along with proof of purchase.
1. GENERAL SPECIFICATIONS - MODEL PT-5500 (190918)
Capacity 5500 lbs. / 2500 kg. Fork Length 48" / 1220 mm
Width 27" / 685 mm Min/Max Ht. 2.95 / 7.25", 75 / 185 mm
Weight 209 lbs. / 95 kg
2. TO ATTACH HANDLE TO PUMP UNIT
2.1 Remove 3 bolts (L111A) from handle shaft (L319A).
2.2 Set handle into bracket (L319A), allowing the chain (L114A) and the adjusting bolt
(L116A) assembly to pass through the hole in the centre of the bracket (L319A)
and shaft (L331A).
2.3 Insert the 3 bolts (L111A) through the handle flange into the handle mounting
bracket (L319A), then tighten them securely.
2.4 Raise the lever (L345) and insert the adjusting bolt (L116A) into the front slot,
keeping the adjusting nut (L117A) on the under side of the lever.
3. TO ADJUST CONTROL LEVER
Your pallet truck features a 3 position control lever. Refer to figure 1.
LIFT lever down
DRIVE lever centred
LOWER lever up (The lever returns to the drive position when released)
