Controls
1 Dioptre Adjustment Control ................. ੬ pg. 11
2 Lens Cover Open/Close Ring................ ੬ pg. 12
3 5-Second Recording Button
[5 SEC REC] ......................................... ੬ pg. 16
4 Power Zoom Lever [T/W]..................... ੬ pg. 14
5 Picture Stabilizer Button
[P. STABILIZER] .................................... ੬ pg. 16
6 Programme AE Button [P.AE] ................ ੬ pg. 18
7 Fade/Wipe Button [EFFECT] ................. ੬ pg. 17
8 •Rewind Button [
2
, REW] ................ ੬ pg. 32
•Retake Rewind Button [RETAKE R] ..... ੬ pg. 15
•Quick Review Button [ R] ............. ੬ pg. 15
9 •Fast-Forward Button [
3
, FF] ............ ੬ pg. 32
•Retake Forward Button [RETAKE F] .... ੬ pg. 15
0 Stop Button [5, STOP] ......................... ੬ pg. 32
! Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. ੬ pg. 32
@ Select Dial [+, –, PUSH] .................. ੬ pg. 7, 22
# MENU/DISPLAY Button ................. ੬ pg. 13, 22
$ Counter Reset/Memory Button
[COUNTER R/M] ................................. ੬ pg. 34
% EJECT Switch ......................................... ੬ pg. 9
^ Recording Start/Stop Button.................. ੬ pg. 12
& Power Switch ................................ ੬ pg. 12, 32
* Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 4
( PUSH Button ......................................... ੬ pg. 9
Connectors
) DC IN Jack ............................................ ੬ pg. 5
The connectors q to r are located beneath the
cover.
q Video Output Connector ...................... ੬ pg. 36
w Audio Output Connector ..................... ੬ pg. 36
e S-Video Output Connector ................... ੬ pg. 36
r J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing (੬ pg. 40– 43).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
t Tally Lamp........................................... ੬ pg. 12
y Power Lamp ........................................ ੬ pg. 12
Other Parts
u Battery Pack Mount ............................... ੬ pg. 4
i Viewfinder ........................................... ੬ pg. 11
o Grip Strap ............................................ ੬ pg. 11
p •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. ੬ pg. 39
Q Microphone......................................... ੬ pg. 45
W Eyepiece .............................................. ੬ pg. 52
E Shoulder Strap Eyelets .......................... ੬ pg. 11
R Clock Battery Slot .................................. ੬ pg. 6
T Tripod Mounting Socket ....................... ੬ pg. 11
