68 KAWAI DIGITAL PIANO CN4
Appendices
1
1st byte
2
2nd byte
3
3rd byte
4
4th byte
5
5th byte
6
6th byte
7
7th byte
8
8th byte
9
9th byte
10
10th byte
MIDI EXCLUSIVE DATA FORMAT
1 F0 . . . . . . . . . . Start code
2 40. . . . . . . . . . Kawai’s ID number
3 00 - 0F . . . . . . MIDI channel
4 10, 30. . . . . . . Function code (30 when setting MULTI TIMBRE ON/OFF)
5 04. . . . . . . . . . Indicates that the instrument is Electronic Piano
6 08. . . . . . . . . . Indicates that the piano is “CN4”
7 data 1
8 data 2 . . . . . . . (See the table below.)
9 data 3
10 F7 . . . . . . . . . . End code
data 1 data 2 data 3 Function
00 00 — Multi Timbre Off
00 01 — Multi Timbre On 1
00 02 — Multi Timbre On 2
0D 00–0C — 00: Effect Off, 01: Chorus 3, 02: Delay 1, 03: Delay 2, 04: Delay 3,
05: Tremolo, 06: Rotary 1, 07: Rotary 2, 08: Chorus 1, 09: Chorus 2
0a: Chorus 4, 0b: FB Chorus, 0c: Flanger
0E 00–03, 06–08 — 00: Reverb Off, 01: Room 2, 02: Stage, 03: Hall 1, 06: Room 1,
07: Hall 2, 08: Plate
14 00–7F — Dual/Split balance
16 1F–60 — Tune, 40: 440 Hz
17 00, 7F — 00: Program Change Off, 7F: Program Change On
18 00–07 — 00: Light, 01: Normal, 02: Heavy, 03: Off, 04: Light+, 05: Heavy+,
06: User 1, 07: User 2
19 00–03 — Lower Octave Shift
20 00–7F 00–7F Dual Program Change, data 2: Right sound, data 3: Left sound
21 00–7F 00–7F Split Program Change, data 2: Upper sound, data 3: Lower sound
25 00–08 00–0B data 2: Temperament, data 3: Key
26 00, 7F 00–0F Multi Timbre, data 2: 00 (On), 7F (Off), data 3: channel
27 00–02 00–02 Dual/Split, Right (Upper)/Left (Lower), sound Bank LSB
