– 32 –
ES3 ES5
Keyboard 88 Keys with Advanced Hammer Action III
Polyphony Maximum 64
Preset Tones Piano (3), E.Piano (3), Piano (4), E.Piano (4),
Organ (3), Harpsi/Mallets (3), Organ (4), Harpsi/Mallets (4),
Strings (3), Choir/Pad (3), Strings (4), Choir/Pad (4),
Bass (3) Bass (4)
Effects Chorus, Tremolo, Delay (3), Rotary (2)
Reverb Room, Stage, Hall
Temperaments Equal (Piano Only), Mersenne pure (Major),
Mersenne pure (minor), Pythagorea, Meantone,
Werckmeister III, Kirnberger III, Equal (flat), Equal
Other Features Master Volume, Dual, Split, Dual/Split Balance,
Transpose, Tune, Sympathetic Resonance, EQ (3)
Touch Curve (Normal, Light (2), Heavy (2), Off),
MIDI (16 part multi-timbral capability)
Recorder 2 Tracks, 4 Songs
The total memory capacity is approximately 10000 notes.
Pedal Sustain, Soft (with optional F-2r foot pedal)
Jacks Headphone (2), LINE IN (Stereo), LINE OUT (L/MONO, R),
PEDAL, MIDI (IN, OUT), USB
Output Power 7W x 2 7W x 2 + 13W
(10W x 2 without stand)
Speakers (12 cm x 8 cm) x 2 (12 cm x 8 cm) x 2
5 cm x 2 (tweeter), 13 cm (woofer)
Dimensions 136.2 x 32.1 x 13.8 cm 137.4 x 39.9x 76.4 cm
(W x D x H) 54” x 13” x 5” 54” x 16” x 30”
Weight 19.5 kg, 43 LB’s 34.6 kg, 76 LB’s
SPECIFICATIONS
Specifications are subject to change without notice.
