210
Controls in detail
Loading
Partition net with rear seats folded
down
1 Tab
2 Eyelets on roof
̈ Pull out upper blind (safety net) by
tabs 1 until it engages.
̈ Fold seat forward (page 211).
̈ Pull out upper blind fully.
̈ Engage it into eyelets on the roof 2.
Luggage cover
Closing
̈ Pull luggage cover back by handle 1
until it locks into position.
Opening
̈ Press handle 1 down and release.
The luggage cover retracts automati-
cally.
Twin-reel roller blind
̈ Retract the safety net and luggage
cover.
Removing
̈ Fold split rear bench seat forward
(
page 211).
̈ Slide twin-reel roller blind 1 to left
and remove.
i
With the luggage cover rolled up, fold
the lip down.
