M.E.Y EQUIPMENT PARTS for 28" MOWER DIAGRAM 2. 9/07/2007
Dwg no Part no Description No
3 FSS51612B Screw set 5/16"x1/2" BSW 2
4 FW516S Washer spring 5/16" 4
5 FW516F Washer flat 5/16" 2
6 FSS381B Screw set 3/8"x1" BSW 4
7 FW38S Washer spring 3/8" 10
8 FW38F Washer flat 3/8" 4
14 B6204RS Bearing 6204RS 4
18 FSS3812B Screw set 3/8"x1/2" BSW 6
21 FN38B Nut 3/8" BSW 6
22 MM053 Housing bearing rear roller 2
22 Prior to 991100 use following parts
22 MM054 Housing bearing rear roller non chain case side 1
22 MM046 Height adjuster rod 1
22 MM047 Height adjuster rod anchor 1
22 FN38B Nut 3/8" BSW 2
61 MM931 Blade bottom 28" - 1mm shaver 1
61 MM932 Blade bottom 28" - 1.5mm shaver 1
61 MM933 Blade bottom 28" - 2mm shaver 1
61 MM934 Blade bottom 28" - 3mm shaver 1
61 MM935 Blade bottom 28" - bevel lipped 1
61 MM936 Blade bottom 28" - thick lipped 1
61 MM937 Blade bottom 28" - thin lipped 1
62 FSC51612C Screw CSK 5/16"x1/2" UNC 13
63 MM967 Blade bottom holder 28" 1
63 MM961 Blade bottom holder 28" prior to 991100 1
64 MM751 Front roller seal 2
65 FC20EXT Circlip retaining 20mm external 2
67 MM755 Front roller shaft 28" 1
68 MM763 Front roller tube 28" 1
68 MM769 Front roller tube and shaft 28" assembled 1
69 MM803 Cylinder 6 blade 28" standard 1
69 MM809 Cylinder 8 blade 28" 1
69 MM815 Cylinder 12 blade 28" 1
70 MM853 Deflector 28" 1
71 MM857 Deflector tab standard 2
71 MM856 Deflector tab prior to 991100 (welded to frame) 2
72 FSS3834B Screw set 3/8"x3/4" BSW 6
73 MM750 Front roller cam height adjusters post 991100 2
74 MM758 Front roller side plates 2
74 MM759 Front roller side plates prior to 991100 2
74 MM772 Front roller side plates for teasing rake & scrapers 2
75 MW002 Washer concave 1/2" post 991100 2
75 FW12S Washer spring 1/2" 2
76 FSS121F Screw set grade 8 1/2"x1" UNF 4
77 FW38ST Washer internal star 3/8" 2
78 FN12NB Nut nyloc 1/2" BSW 1
79 FN12B Nut 1/2" BSW 1
80 MM028 Clutch fork boss 1
81 FM004 Pin split 2
82 FSS124B Screw set 1/2"x4" BSW 1
83 FSS5161B Screw set 5/16"x1" BSW 2
84 FN516B Nut 5/16" BSW 2
85 MM029 Clutch fork pair 1
86 MM030 Clutch lever 1
87 MM045 Handle grip clutch lever 1
89 MM631 Back roller 28" 1
89 MM636 Back roller 28" prior to 991100 1
90 MM086 Throttle lever 1
91 FN316B Nut 3/16" BSW 2
92 FB316114B Bolt roofing 3/16"x1 1/4" BSW 2
93 FB141F Bolt 1/4"x1" UNF 1
94 MM037 Drive lever spacer bush 1
95 MM036 Drive lever bronze 1
96 FN14NF Nut nyloc 1/4" UNF 1
97 MM044 Handle grip, pair 1
100 MB121F Bolt 1/2"x1" UNF (machined head) 2
101 MM085 Throttle cable 1
142 FW12ST Washer internal star 1/2" 4
