EasyTouch Load Center Installation Guide
EasyTouch 8 and 4 Pool and Spa Control System Kit Contents
The following items are included in the EasyTouch 8 and EasyTouch 4 control system kit which may
also include the IntelliChlor cell. If any items are missing please contact Technical Support.
• EasyTouch control panel (mounted in the load center)
• EasyTouch load center enclosure
• Two motorized valve actuators (CVA-24T P/N 263045) - Not included with single-body
system
• Water sensor with 25 foot cable, o-ring and hose clamp (P/N 520272)
• Air sensor with 25 foot cable (P/N 520272)
• EasyTouch 8 and EasyTouch 4 Pool and spa Control System Installation Guide
(this manual)
Optional Equipment
• IntelliChlor Electronic Chlorine Generator Electrolytic Cell (model IC20 (P/N 520554) or
IC40 (P/N 520555)
• IntelliChlor User’s Guide (P/N 520589)
About this manual
Use the information in this manual for installing the EasyTouch 8 or 4 Control System kit contents.
• For EasyTouch system operating instructions, refer to the EasyTouch User’s Guide
(P/N 520584)
• For Accessory installation and operation instructions, refer to the documentation provided
with the accessory
EasyTouch Accessory Equipment
iS4 Spa-Side Remote
Controller (P/N 520094)
QuickTouch Remote
Controller (P/N 520148)
EasyTouch 4 Indoor Control
Panel (P/N 520548)
EasyTouch 8 Indoor Control
Panel (P/N 520549)
POWER ON
EasyTouch Wireless Control Panel
(8 circuit) (P/N 520547)
