19
HDMI output: 480i, 480p, 576i, 576p, 720p, •
1080i, 1080p
Audio
Analog stereo output•
Signal to noise ratio (1 kHz): > 90 dB (A-weighted)•
Dynamic Range (1 kHz): > 80 dB (A-weighted)•
Crosstalk (1 kHz): > 90 dB•
Distortion/noise: (1 kHz): > 75 dB•
MPEG MP3: MPEG Audio L3•
Digital output•
Coaxial•
HDMI output•
Main unit
Dimensions (w x h x d): 360 x 39 x 209 (mm)•
Net Weight: approximately 1.48 kg•
Power
Power supply rating: 110 - 240V, 50/60HZ•
Power consumption: < 10 W•
Power consumption in standby mode: < 0.1 W•
Accessories supplied
Remote control and batteries•
HDMI cable•
Audio/Video cables•
User Manual•
Quick Start Guide•
Laser specifi cation
Type: Semiconductor laser InGaAIP (DVD), •
AIGaAs (CD)
Wave length: 655 nm (DVD), 790 nm (CD)•
Output Power: 7.0 mW (DVD), 10.0 mW •
(VCD/CD)
Beam divergence: 60 degrees•
9 Troubleshooting
Warning
Risk of electric shock. Never remove the casing of the •
product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, register your product and get
support at www.philips.com/welcome.
If you contact Philips, you will be asked for the model
and serial number of your product. The model
number and serial number are on the back of your
product. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
8 Additional information
Update software
For software updates, check the current software
version of this product to compare with the latest
software (if available) at the Philips website.
Caution
Power supply must not be interrupted during software •
upgrade.
1 Press SETUP.
2 Select [Preferences] > [Version Info], and
then press OK.
3 Write down the fi le name, and then press
SETUP to exit the menu.
4 Visit www.philips.com/support to check for
the latest software version, using the fi le name
for this product.
5 Refer to the upgrade instructions on the
website for more information.
Note
Disconnect the power cord for a few seconds and •
connect again to turn on the product.
Care
Caution
Never use solvents such as benzene, thinner, cleaners •
available commercially, or anti-static sprays intended for discs.
Clean discs
Wipe the disc with a micro fi bre cleaning cloth from
the centre to the edge in a straight line movement.
Specifi cations
Note
Specifi cation and design are subject to change without notice•
USB
Compatibility: Hi-Speed USB (2.0)•
Class support: UMS (USB Mass Storage Class)•
Video
Signal system: PAL / NTSC•
Composite video output: 1 Vpp ~ 75 ohm•
Component video output: 0.7 Vpp ~ 75 ohm•
English
EN
