Chapter 6 INSTALLING THE CONVERTER
6.1 Stand-alone Installation
To install a GT-80X stand-alone, on a desktop or shelf,
simply complete the following steps:
Step 1: Turn off the power of the device/station in a
network to which the GT-80X will be attached.
Step 2: Ensure that there is no activity in the network.
Step 3: Attach ber cable from the GT-80X to the ber
network. TX, RX must be paired at both ends.
Step 4: Connect the 5VDC power adapter to the GT-80X
and verify that the Power LED lights up.
Step 5: Turn on the power of the device/station; the PWR
LEDs should light when all cables are attached.
