Exploded View/Disassembly&Assembly Instructions
5-2
5-2. Cellular phone Parts list
Design LOC
Description Sec Code
QAN02
INTENNA-SGHE898 GH42-00955A
QBA00
PMO-COVER BATT GH72-33166A
QBA01
INNER BATTERY PACK-880MAH,BLK, GH43-02323A
QBR01
NDC-BRAKET DOMESHEET GH71-06759A
QCA01
UNIT-CAMERA GH59-03358A
QCA06
NDC-BRAKET CAMERA GH71-06760A
QCR04
SCREW-MACHINE 6001-001479
QCR05
SCREW-MACHINE 6001-001478
QKP01
ASSY KEYPAD-(TIY/SIL) GH98-01807A
QLC01
LCD-SGH-E898 GH07-00969A
QME01
UNIT-MAIN KEY FPCB GH59-03373A
QMO01
MOTOR DC-SGHE898 GH31-00273A
QMP01
PBA MAIN-SGHE890S GH92-03152A
QRE01
ASSY CASE-REAR GH98-01806A
QRF01
PMO-COVER RF GH72-32726A
QRF03
PMO-COVER EAR JACK GH72-32714A
QSC01
RMO-COVER SCREW GH73-07720A
QSP01
SPEAKER 3001-002028
QST01
ASSY ACCE-STYLUS PEN(SIL_SAM) GH98-02835F
QFR01
ASSY CASE-FRONT GH98-02838A
QCK01 PMO-CAMERA KEY GH72-33664A
QCK02 PMO-HOLD KEY GH72-33666A
QSD01 PMO-COVER SD GH72-32715A
QVO01 PMO-VOLUME KEY GH72-33665A
