PART NO. DESCRIPTIONREF NO. QTY.
32" Mower Deck - Height Adjustment Group
Footnotes
1 5025162 4 WASHER, 1” SAE
2 5047682B 1 DECK LIFT PIVOT - REAR
3 5025356 8 SHOULDER BOLT, 1/2 x 3/8
4 5047655 1 HEIGHT ADJUST ROD
5 5048526 1 LINKAGE ADJUSTER
6 5025100 1 NUT, 3/8-16 Hex Side Lock
7 5025201X6 1 COTTER PIN, 3/32” x 3/4”
8 5025046 8 NUT, 3/8-16 Hex Top Lock
9 5010546 1 COLLAR, 3/8” Set
10 5025156 6 WASHER, 3/8” SAE
11 5022645 1 SPRING, Compression
12 5047710B 4 DECK ADJUST LINK
13 5025011X8 4 BOLT, 5/16-18 x 1
14 5025139 4 NUT, 5/16-18 Hex Large Serrated Flange
15 5025013X10 2 BOLT, 3/8-16 x 1-1/4
16 5044933 2 SPACER, .39 x .75 x .38
17 5048549 2 COLLAR, Double Split, 1”
18 5025128 7 NUT, 3/8-16 Hex Serrated Flange
19 5047737 1 CUT HEIGHT INDICATOR
20 5025034 1 NUT, 3/8-16 Hex
21 5047681B 1 DECK LIFT PIVOT - FRONT
22 5025013X6 4 BOLT, 3/8-16 x 3/4
23 5048439B 2 HANGER PLATE
24 5020095 1 GREASE FITTING
25 5048548 1 WASHER, 3/8” NYLON HYDRO CUT
The above parts group applies to the following Mfg. Nos.:
2008
33
© Copyright Briggs and Stratton. All Rights Reserved.
5901182
HC32KAV13E
32" 13 HP H
dro
TP 400-7336-B-HC-SN
