42
US
1 Confirm the measurement
result.
When the measurement ends, a beep
sounds.
2 Press V/v to select the item you
want, then press .
* When the speaker(s) is (are) out of the phase,
“OUT” is displayed on the TV screen. The
“+” and “–” terminals of the speaker may be
connected the other way around.
However, depending on the speakers, “OUT”
appears on the TV screen even though the
speakers are connected properly. This is
because of the speakers’ specifications. In
this case, you can continue to use the
receiver.
3 Select “Save” in step 2 to save
the measurement result.
4 Press V/v repeatedly to select
the Auto Calibration Type, then
press .
Confirming/saving the
measurement results
Item Explanation
Retry Performs the Auto Calibration
again.
Save Saves the measurement
results and exits the setting
process.
Warning Displays warning concerning
the measurement results. See
“Message list after Auto
Calibration measurement”
(page 43).
Phase* Displays the phase of each
speaker (in phase/out of
phase).
Distance Displays the measurement
result for speaker distance.
Level Displays the measurement
result for speaker level.
Exit Exits the setting process
without saving the
measurement results.
Parameter Explanation
Full Flat Makes the measurement of
frequency from each speaker
flat.
Engineer Sets the frequency
characteristics to a set that
matches that of the Sony
listening room standard.
Front
Reference
Adjusts the characteristics of
all the speakers to match the
characteristics of the front
speaker.
Off Sets the Auto Calibration EQ
to off.
