Models 750, 751, 754, 774, 791, 794 Operating Procedures
Step 7
Snap the design cap(s) over the end of the door
spout(s).
Figure 16
Step 8
Install the front drip tray and the splash shield under
the door spout(s).
Figure 17
Step 9
Slide the rear drip pan(s) into the hole in the side panel.
Figure 18
Models 791 & 794: Slide the rear drip pan into the hole
in the front panel.
Step 10
Slide two o- rings on one end of the a ir tube. Slide two
o- rings on the other end of the air tube.
Figure 19
Slide the small o- ring into the groove of the air orifice.
Do not lubricate the o- ring.
Figure 20
Note: Make sure the hole in the air orifice is clean and
is not clogged. If the hole in the air orifice should
become clogged, use soap and hot water to clear the
hole. Do not enlarge the hole in the air orifice.
