5.19MACInterruptMaskSetRegister(MACINTMASKSET)
5.20MACInterruptMaskClearRegister(MACINTMASKCLEAR)
EthernetMediaAccessController(EMAC)Registers
TheMACinterruptmasksetregister(MACINTMASKSET)isshowninFigure59anddescribedin
Table58.
Figure59.MACInterruptMaskSetRegister(MACINTMASKSET)
3116
Reserved
R-0
15210
ReservedHOSTMASKSTATMASK
R-0R/W1S-0R/W1S-0
LEGEND:R=Readonly;R/W=Read/Write;W1S=Write1toset,writeof0hasnoeffect;-n=valueafterreset
Table58.MACInterruptMaskSetRegister(MACINTMASKSET)FieldDescriptions
BitFieldValueDescription
31-2Reserved0Reserved
1HOSTMASK0-1Hosterrorinterruptmasksetbit.Write1toenableinterrupt,awriteof0hasnoeffect.
0STATMASK0-1Statisticsinterruptmasksetbit.Write1toenableinterrupt,awriteof0hasnoeffect.
TheMACinterruptmaskclearregister(MACINTMASKCLEAR)isshowninFigure60anddescribedin
Table59.
Figure60.MACInterruptMaskClearRegister(MACINTMASKCLEAR)
3116
Reserved
R-0
15210
ReservedHOSTMASKSTATMASK
R-0R/W1C-0R/W1C-0
LEGEND:R=Readonly;R/W=Read/Write;W1C=Write1toclear,writeof0hasnoeffect;-n=valueafterreset
Table59.MACInterruptMaskClearRegister(MACINTMASKCLEAR)FieldDescriptions
BitFieldValueDescription
31-2Reserved0Reserved
1HOSTMASK0-1Hosterrorinterruptmaskclearbit.Write1todisableinterrupt,awriteof0hasnoeffect.
0STATMASK0-1Statisticsinterruptmaskclearbit.Write1todisableinterrupt,awriteof0hasnoeffect.
SPRUEQ6–December2007EthernetMediaAccessController(EMAC)/ManagementDataInput/Output(MDIO)101
