Revision J
No. Description Part Number (History)
1 Screw-#6-18 X 1/4 TAP PHD PHPS M067883-03 (98-04160, 98-2052)
2 Guide-Top Receipt 20-04432 (20-02542)
3 Roller-Pressure 12-01506 •
4 Assy-Platen 12-03311 •
5 Disk-Wiper 20-03176
6 Wiper-Cartridge 98-03326
7 Screw-#2 Plastic Thd Forming 98-02592 •
8 Switch-Momentary Lever 98-02098L (98-02098)
9 Na Na
10 Arm-Paper Out 12-01547
11 Roller-Receipt 12-05129 (12-01521)
12 Guide-Std Receipt
Guide-Receipt w/Knife
20-04718L (20-04165,20-02557) •
20-04719L (20-04166, 20-02553) •
13 Strap-Ground 20-03558 •
14 Spring-Paper Drive 20-02550 •
15 Frame-Drive 20-02525 •
16 Shaft-Wiper 12-01531 •
17 Arm-Wiper 20-04724 • (20-03164)
18 Screw-4/40 98-01595
19 Spittoon 12-01548 •
20 Guide-Upper Slip 20-03157 •
21 Spring-Wiper Extension 98-03601 (98-01592)
22 Arm-Solenoid 12-01529 •
23 Assy-Solenoid 12-02213l (12-02213)
24 Bearing-Driveframe 20-04716
Table 7 Drive Support Assembly Parts List
• Not available as a spare part
